Spectre Corp provides components for the nation's defense
-
Model 1000 General Purpose Pressure Transducer
Model 1000 General Purpose Pressure Transducer
• Eliminate Drift – Fused Bond sensor technology for long-term stability
• Eliminate Noise – Maximum RFI/EMI protection on every transducer
• Outputs - 4-20mA, 0-5V & 0-10V – custom outputs available
• Pressure ranges 0-10" WC to 0-60,000 PSI
• Accuracies to 0.1% BFSL
• Unparalleled long-term stability
• Temperature compensation at the sensor element.
• Custom designs available (contact factory)
Spectre's Model 1000 is specifically engineered to eliminate the two most common problems with pressure transducers, noise and drift. It's large, raw sensor output (10-70X that of a bonded foil strain gauge device), The long term stability of Model 1000 and standard RF!/EMI protection provide the most rugged and reliable transducer for industrial applications. Originally designed to withstand the rigorous testing requirements of defense and space applications, The Model 1000 offers aerospace performance to the industrial marketplace.
-
Model 9000 Precision Pressure Transducer
Model 9000 Precision Pressure Transducer
• ±0.05% Total Error Band from -40°C to +85°C
• Optional Push Button re-zero function
• Transducer is customized to your specific temperature and pressure conditions
• Outputs: 4-20mA, 0-5 Vdc, 0-10 Vdc. Optional 4-wire, isolated outputs and RS232/RS485 available.
• Pressure ranges 0-10" WC to 30,000 PSI
• Built-in, proprietary design, lightning and surge protection supplied as standard
• Unparalleled long-term stability
Spectre's Series 9000 is the first available pressure transducer that is designed, manufactured and calibrated to each application's specific operating conditions. Each transducer's output is digitally mapped to correct for any non-linearity or inaccuracies in the sensing element. This digital correction provides the most accurate and flexible pressure transducer in the industry.
-
Model 9500 Precision Combination Series
Model 9500 Precision Combination Series
• Transmitter is customized to your specific temperature and pressure conditions
• Flexible – Transmitter output can be mapped to enhance accuracy at any specific Temperature or Pressure range.
• Multiple Outputs – 4-20mA, 0-5V, 0-10V, RS232 and RS485
• Suitable for high shock and vibration applications
• No Silicone oil, no internal o-rings, no welded diaphragms!
• Ranges 0-10" WC to 30,000 PSI
• Gauge, Sealed Gauge, Absolute ranges
Spectre's 9500 Precision Series Pressure Transducers offer the first available sensors that are manufactured, designed and calibrated to each customers specific operating conditions. Each transducer output is digitally mapped to correct for any non-linearity or inaccuracies in the sensor. This digital correction and the inherent advantages of the fused bond sensor provide the most accurate and flexible transducer in the industry. Additionally, the unit can be designed for high pressures and still retain accuracies in the lower pressure range (i.e.:10,000 psi sensor can accurately measure below 500 psi), or provide high accuracy in one specific area of the pressure range (i.e.: 500 psi sensor with highest accuracy band between 40-60 psi).
-
Model 9510U USB Enabled Pressure Transducer
Model 9510U USB Enabled Pressure Transducer
• Direct USB 2.0 connection to data acquisition and test systems
• Transducer is custom configured to your specific temperature and pressure conditions
• ASCII data output to interface with virtually DAQ or control system
• Pressure ranges 0-10" WC to 0-30,000 PSI
• Gauge, sealed and absolute ranges
• Accuracies to 0.03% BFSL
• Unparalleled long-term stability
• Cable lengths to 300 feet (consult factory)
• Pressure and temperature data supplied from one device.
• Maximum RFI/EMI protection on every transducer
• Temperature compensation at the sensor element.
• Custom designs available (contact factory)
Spectre's 9510U USB Pressure/Temperature Transducers offer the first precision USB 2.0 enabled sensors on the market that are designed and calibrated to each customer's specific operating conditions. Each transducer is digitally mapped to correct for any non-linearity or inaccuracies in the sensor. This digital correction provides the most accurate and flexible transducer in the industry.
-
Model D950 Precision Differential Series Pressure/Temperature Transducer
Model D950 Precision Differential Series Pressure/Temperature Transducer
• Transmitter is customized to your specific temperature and pressure conditions
• Flexible – Transmitter output mapped to enhance accuracy at any specific Temperature or Pressure range.
• Multiple Outputs – 4-20mA, 0-5V, 0-10V, RS232, RS485, TC, RTD and USB 2.0
• Ranges 0-5 PSID to 1,000 PSID
Spectre's D950 Differential Series Pressure Transducers offer the first available sensors that are manufactured, designed and calibrated to each customers specific operating conditions. Each transducer output is digitally mapped to correct for any non-linearity or inaccuracies in the sensor. The Model D950 offers wet/wet differential pressure measurements of gases and liquids compatible with stainless steel.
