Model 1000 General Purpose Pressure Transducer

• Eliminate Drift – Fused Bond sensor technology for long-term stability

• Eliminate Noise – Maximum RFI/EMI protection on every transducer

• Outputs - 4-20mA, 0-5V & 0-10V – custom outputs available

• Pressure ranges 0-10" WC to 0-60,000 PSI

• Accuracies to 0.1% BFSL

• Unparalleled long-term stability

• Temperature compensation at the sensor element.

• Custom designs available (contact factory)

Spectre's Model 1000 is specifically engineered to eliminate the two most common problems with pressure transducers, noise and drift. It's large, raw sensor output (10-70X that of a bonded foil strain gauge device), The long term stability of Model 1000 and standard RF!/EMI protection provide the most rugged and reliable transducer for industrial applications. Originally designed to withstand the rigorous testing requirements of defense and space applications, The Model 1000 offers aerospace performance to the industrial marketplace.

Data sheet

Model 1500 Pressure/Temperature Transducer

• Temperature & Pressure outputs from one transducer

• Eliminate Drift - Fused Bond sensor technology for long-term stability

• Eliminate Noise – Maximum RFI/EMI protection on every transducer

• Outputs - 4-20mA, 0-5V & 0-10V – custom outputs available

• Pressure ranges 0-1 to 0-60,000 PSI

• Accuracies to 0.1% BFSL

• Unparalleled long-term stability

• Temperature compensation at the sensor element.

• Custom designs available (contact factory)

Spectre's Model 1500 transducer incorporates all of the features of the Model 1000 with the addition of a temperature output. It's large, raw sensor output (10-70X that of a bonded foil strain gauge device), Long term stability of the Model 1500 and standard RF!/EMI protection provide the most rugged and reliable transducer for industrial applications. Originally designed to withstand the rigorous testing requirements of defense and space applications, The Model 1500 offers aerospace performance to the industrial marketplace.

Data sheet

Model 3000 Hydraulic Pressure Transducer

• Designed specifically for applications where high shock and vibration are present

• Eliminate Drift – Fused Bond Sensor technology for long-term stability

• Sensor wetted material machined from solid stainless steel bar stock. No Silicone oil fill, no internal o-rings, no welded diaphragms!

• Eliminate Noise – Maximum RFI/EMI protection on every transducer

• Outputs - 4-20mA, 0-5V & 0-10V

• Pressure ranges 0-15 to 0-40,000 PSI

• Accuracies to 0.04% BFSL

• Unparalleled long-term stability

• Temperature compensation at the sensor element.

The rugged design of the Spectre Model 3000 Hydraulic Series pressure transducer makes it the ideal choice when application conditions such as high vibration, shock and temperature extremes are present. Typical applications for the Model 3000 are industrial OEM equipment, injection molding, die casting and hydraulic systems with pressure spikes or highly cyclic conditions.

Data sheet

Model 9000 Precision Pressure Transducer

• ±0.05% Total Error Band from -40°C to +85°C

• Optional Push Button re-zero function

• Transducer is customized to your specific temperature and pressure conditions

• Outputs: 4-20mA, 0-5 Vdc, 0-10 Vdc. Optional 4-wire, isolated outputs and RS232/RS485 available.

• Pressure ranges 0-10" WC to 30,000 PSI

• Built-in, proprietary design, lightning and surge protection supplied as standard

• Unparalleled long-term stability

Spectre's Series 9000 is the first available pressure transducer that is designed, manufactured and calibrated to each application's specific operating conditions. Each transducer's output is digitally mapped to correct for any non-linearity or inaccuracies in the sensing element. This digital correction provides the most accurate and flexible pressure transducer in the industry.

Data sheet

Model D150 Differential Pressure Transducer

• Accuracies of 0.5%, 0.2% & 0.1%

• Maximum RFI/EMI protection on every transducer

• Outputs - 4-20mA, 0-5V & 0-10V – custom outputs available

• Pressure ranges 0-5 to 0-1,000 PSID

• Suitable for high shock and vibration applications

• Available with temperature output (thermocouple or RTD)

• Temperature compensation at the sensor element.

• Custom designs available (contact factory)

Data sheet

Model D950 Precision Differential Series Pressure/Temperature Transducer

• Transmitter is customized to your specific temperature and pressure conditions

• Flexible – Transmitter output mapped to enhance accuracy at any specific Temperature or Pressure range.

• Multiple Outputs – 4-20mA, 0-5V, 0-10V, RS232, RS485, TC, RTD and USB 2.0

• Ranges 0-5 PSID to 1,000 PSID

Spectre's D950 Differential Series Pressure Transducers offer the first available sensors that are manufactured, designed and calibrated to each customers specific operating conditions. Each transducer output is digitally mapped to correct for any non-linearity or inaccuracies in the sensor. The Model D950 offers wet/wet differential pressure measurements of gases and liquids compatible with stainless steel.

Data sheet
